Product Overview
Propack ESD Resistance Testers are precision instruments designed for measuring electrical resistance and resistivity of ESD control materials including floor coverings, mats, wrist straps, footwear, packaging materials, and workbench surfaces. Accurate, repeatable measurement is essential for qualifying new materials and for periodic compliance verification in your EPA.
Available in handheld portable format for in-field testing and benchtop laboratory models for comprehensive characterization, our testers support test voltages of 10V, 100V, and 500V as required by ANSI/ESD S11.11 (bags), S4.1 (worksurfaces), S7.1 (flooring), and S1.1 (wrist straps). Digital display with auto-range, data logging, and optional PC connectivity for test record generation.
Key Features
Wide Measurement Range
Measures from 10³ Ω to 10¹² Ω with auto-ranging. Covers all ESD material classes — conductive, dissipative, and insulative.
Multi-Voltage Test
Selectable test voltages: 10V (wrist straps), 100V (worksurfaces/packaging), 500V (flooring/footwear). Single instrument covers all ANSI/ESD standards.
Data Logging
Internal storage for 1000+ readings with timestamp. USB output for transfer to PC and generation of compliance test reports.
Portable & Rechargeable
Built-in rechargeable Li-ion battery provides 8+ hours of operation. Compact, rugged housing for use on production floor and field audits.
PASS/FAIL Indication
Configurable PASS/FAIL limits with audible beep and colour-coded LED display. Simplifies large-scale periodic testing of operator footwear and wrist straps.
Multiple Probe Options
Interchangeable concentric ring probe (surface), parallel probe (P-to-P resistance), and electrode plate sets for comprehensive material testing.
Technical Specifications
| Measurement Range | 10³ – 10¹² Ω (auto-range) |
|---|---|
| Test Voltages | 10 V, 100 V, 500 V (selectable) |
| Accuracy | ±5% of reading (10³–10⁹ Ω); ±10% (10⁹–10¹² Ω) |
| Display | 4-digit LCD with scientific notation (e.g., 1.23 × 10⁸) |
| Applicable Standards | ANSI/ESD S11.11, S4.1, S7.1, S1.1, IEC 61340-2-3 |
| Data Memory | 1000 readings with timestamp |
| Interface | USB-B for PC data transfer |
| Power | Li-ion 3.7V / 2600 mAh rechargeable; 8+ hours |
| Dimensions (handheld) | 195 × 90 × 45 mm, 450 g |
| Operating Conditions | 15°C–35°C, 10–70% RH (non-condensing) |
