Product Overview
The Body Voltage Meter measures the electrostatic charge generated on personnel — a critical measurement for ensuring operators are not bringing dangerous static voltages into your ESD protected area. Human body model (HBM) ESD events from charged personnel remain one of the leading causes of latent and catastrophic device damage in electronics manufacturing.
Propack Body Voltage Meters are available as compact handheld units for operator self-testing and as fixed-panel mounted monitors for continuous supervisory monitoring at workstations. The instrument provides direct readout in volts, with programmable PASS/FAIL limits and audible alert for non-compliant readings.
Key Features
Direct Voltage Readout
Measures body charge in volts (−4000V to +4000V range). Instant digital display for rapid operator self-check at EPA entry points.
PASS/FAIL Indication
Configurable alarm threshold (typically ±100V). Green LED = PASS; Red LED + audible = FAIL. Ideal for entry control stations.
Peak Hold Function
Captures maximum charge voltage during movement — identifies charge-generating activities like walking, sitting, and reaching.
Wrist Strap Compatibility
Test plate design compatible with standard ESD wrist strap plug-in testing. Measure wrist strap ground continuity and body voltage simultaneously.
Data Logging
500+ reading memory with operator ID input. Supports compliance audit trails and periodic charge monitoring records.
Long Battery Life
9V alkaline or rechargeable operation. Low battery indicator. Up to 200 hours of continuous operation on single battery.
Technical Specifications
| Measurement Range | −4000 V to +4000 V DC |
|---|---|
| Resolution | 1 V |
| Accuracy | ±5% of reading ±10 V |
| Input Impedance | ≥ 10¹⁴ Ω (non-loading measurement) |
| Display | 4-digit LCD with sign |
| PASS/FAIL Threshold | ±50 V, ±100 V, ±200 V (user-configurable) |
| Data Memory | 500 readings with date/time stamp |
| Power | 9 V battery; 200 hr operation |
| Standard Reference | ANSI/ESD S20.20, IEC 61340-5-1 |
| Weight | 180 g (including battery) |
