Product Overview
The ESD Entry Control Gate is a fully automated system that tests operators for ESD compliance every time they enter an EPA. The system simultaneously tests wrist strap continuity and footwear resistance using conductive floor plates and wrist strap socket — if both tests pass, the gate opens; if either fails, entry is denied and an alert is generated.
Propack Entry Control Gates are available as standalone test stations (without physical barrier), flap-barrier turnstiles, and full turnstile gates for high-security facilities. All models feature operator ID badge integration, test result logging, and network connectivity for central compliance reporting. The system enforces 100% operator testing compliance — eliminating the inconsistency of self-reported manual testing.
Key Features
Footwear + Wrist Strap Test
Simultaneous testing of both wrist strap resistance and shoe/foot resistance from floor test plates. Complete operator ESD compliance check in <3 seconds.
Badge Reader Integration
RFID/barcode badge reader links test result to operator ID. Creates individual compliance records for ESD audit trail and non-compliant operator tracking.
Physical Gate Control
Relay output controls electromagnetic door lock, flap barrier, or full turnstile. FAIL result physically prevents EPA entry — enforcing compliance 24/7.
Network Logging
Ethernet/Wi-Fi connectivity. All test results (pass/fail, operator ID, time/date) logged to central server. Real-time dashboard for compliance monitoring.
Compliance Reporting
Automated daily/weekly compliance reports. Identifies consistently non-compliant operators for retraining. Exportable to Excel/PDF for ESD audit documentation.
Configurable Test Limits
PASS/FAIL limits configurable per ANSI/ESD S20.20 or custom standards. Separate thresholds for wrist strap (0.75–35 MΩ) and footwear (<100 MΩ).
Technical Specifications
| Wrist Strap Test Range | 750 kΩ – 35 MΩ (configurable PASS limit) |
|---|---|
| Footwear Test Range | 10 kΩ – 100 MΩ per ANSI/ESD S20.20 |
| Test Voltage | 9 V DC (wrist strap); 10 V DC (footwear plates) |
| Test Duration | < 2 seconds (simultaneous wrist + both feet) |
| Gate Types | Test-only station / Flap barrier / Full turnstile |
| ID Input | RFID (Mifare/HID), barcode, keyboard entry |
| Connectivity | Ethernet RJ-45, optional Wi-Fi, USB-B |
| Data Logging | 50,000 records internally; unlimited on network server |
| Display | 7" colour touchscreen with pass/fail graphical display |
| Compliance | ANSI/ESD S20.20, IEC 61340-5-1 |
